2500m3/h Cutter Suction Dredger
Dredge Boat for Sale
Advantages of our dredgers
It is specific type of dredging vessel with a pumping capacity of 2500 cubic meters per hour. This vessel is primarily designed for excavation, filling, and dredging operations in various water bodies, including coastal areas, rivers, reservoirs, canals, and more.
- Main hull material: Steel and Steel Aluminum Ship
2500m/h Cutter Suction Dredger Ship Specification
Total Length * Width * Height | Customized according to customer requirements |
Main Hull | Customized according to customer requirements |
The Maximum Dredging Depth | Customized according to customer requirements |
Main Engine Brand name | Cummins/Weichai |
Winch | The big arm winch, travelling winch |
Classification Society Certification
Performance Features
The 2500m3/h Cutter Suction Dredger Vessel is a specialized dredging vessel designed for excavation, filling, and dredging operations in water bodies such as coastal areas, rivers, reservoirs, canals, and more. With a pumping capacity of 2500 cubic meters per hour, it offers a balance between efficiency and productivity.
Equipped with a cutter head, the dredger vessel can effectively cut through soil, sediments, and other materials present on the seabed or riverbed. The cut material is then drawn in through a suction pipe and transported to a designated location for disposal or further processing.
The 2500m3/h Cutter Suction Dredger Vessel plays a crucial role in various applications. It is commonly used for maintaining navigable channels, deepening waterways, land reclamation, infrastructure development, environmental remediation, and other dredging tasks. By removing sediments and maintaining proper water depths, it ensures smooth navigation, prevents flooding, and supports sustainable development.
2500m3/h Dredger Technical Parameter Table
Water flow | 2500m3/h |
Solid sand capacity | 500m3/h |
Max. dredging depth | 12m |
Discharge distance | 2000m |
Draught | 1.1m |
Weight | 110T |
Total power | 985w |
Total fuel oil consumption | 107kg/h |
Dredger LOA | 30m |
Hull size(LxBxH) | 22mx6.8mx1.8m |
Main pontoon(L×B×H) | 14mx3.2mx1.8m |
Side pontoon(LxBxH) | 22mx1.8mx1.8m |
Structure | Can be dismantled and re-assembled easily. box structure,lower delivery cost |
Main engine brand & power | WEICHAI/735kw |
Auxiliary engine brand & power | WEICHAI/230kw |
Harbour generator | 20kw |
Dredging pump | Warman Technology |
Discharge pipe Dia. | 400mm |
Head | 60m |
Cutter head Dia. | 1600mm |
Cutter power | 150kw |
Hydraulic control system | PLC Siemens |
Ladder Winch force & Quantity | 80KN*1 |
Swing Winch force& Quantity | 80KN*2 |
Operation room | Adjustable chair, movable side-window. air condition,PLC system, signal lights and floodlights. |
